Avo­lites Are­na DMX Light­ing Console

Manufacturer: Avo­lites

Model Number: Avo­lites Arena

$ 400.00 / day
Lighting Lighting Consoles

The Avo­lites Are­na is the ide­al desk for fes­ti­vals, the­atres and any­where that a larg­er con­trol sur­face is required. It com­bines the pop­u­lar inter­face of the Tiger Touch II with more live con­trol than ever before.

Along­side the vibrant main dis­play, a sec­ond touch screen pro­vides an addi­tion­al work­space win­dow, also labelling the adja­cent macro but­tons and rotary pots. These ful­ly assign­a­ble play­back encoder pots, allow intu­itive con­trol of chan­nels and effects. The six LCD screens dis­play elec­tron­ic leg­ends for 30 faders, for speedy access to all your play­backs, fix­tures and palettes. A brand new opti­cal out­put means the Are­na is equipped for fibre con­nec­tions, with no sig­nal loss over long dis­tances, from front of house to the stage – essen­tial in large and out­door venues.

Offer­ing seam­less Mul­ti User com­pat­i­bil­i­ty, the Are­na can be used as mas­ter, back-up or extra pro­gram­ming sur­face, con­sid­er­ably cut­ting your pro­gram­ming time by allow­ing mul­ti­ple Titan pro­gram­mers to work simul­ta­ne­ous­ly, before the main con­sole takes charge.

  • 40 pre­ci­sion play­back faders in three page­able groups.
  • 20 pro­gram­ma­ble macro execu­tor buttons.
  • 3 met­al shaft opti­cal attribute encoders.
  • 4 opti­cal play­back encoder pots.
  • 15.6” vibrant main touch screen with bright­ness control.
  • 7” vibrant sec­ondary touch screen.
  • 6 mono LCD screens for dig­i­tal fad­er legends.
  • UPS bat­tery back-up
  • New six-posi­tion artic­u­la­tion stand
  • Ergonom­ic trim and car­ry handles
  • Robust stain­less and zinc treat­ed steel con­struc­tion – built for life on the road
  • Includes 4-port man­aged Giga­bit net­work switch
  • Opti­cal­CON Stage link out­put, with an option­al sec­ond link
  • 8 phys­i­cal 5-pin XLR opto-iso­lat­ed DMX out, up to 16 uni­vers­es over Art­Net or stream­ing ACN – total of 8192 con­sole channels.
  • Com­pat­i­ble with Titan Net – up to 64 uni­vers­es, total of 32,768 sys­tem channels.
  • 4 Ether­con Giga­bit pri­ma­ry net­work con­nec­tion with a bat­tery main­tained man­aged switch sup­port­ing Titan Net, Art­Net and stream­ing ACN.
  • 1 Ether­con Giga­bit sec­ondary Net­work con­nec­tion for Titan Net, Art­Net and stream­ing ACN.
  • 1 stan­dard Opti­cal­CON stage link out­put, to con­nect to indus­try stan­dard net­work switch­es with opti­cal support.
  • SMPTE Timecode/​LTC input 3-pin XLR (trans­former isolated).
  • Trig­ger inputs on ¼” jack, suit­able for foot switches.
  • Audio in on stereo ¼” jack for Audio Triggering.
  • Head­phone 3.5mm jack con­ve­nient­ly placed on the front panel.
  • 4 USB3 ports – 1 front, 3 rear.
  • DVI-D for exter­nal display.
  • Two 3-pin XLR dim­ma­ble lamp connector
  • MIDI in, out and thru.
  • Com­pat­i­ble with Titan Remote (Wi-Fi access point required)
  • Includes: Flight Case, Dim­ma­ble Lamp x2, Cover
